C770V1 Century Motor 1HP 1075RPM M56Y OAO 460/200-230 Volt 1 Phase

This Marathon Century Motor offers reliable performance with 1 HP and 1075 RPM. Featuring an automatic reset thermal protector, it prevents overheating. The patented MAXGuard® insulation system provides superior protection for variable frequency drive applications. Permanently lubricated, double-sealed bearings ensure extended motor life, while the ability to operate in ambient temperatures up to 70°C allows for consistent performance in diverse environments. Its vertical/horizontal mounting offers flexibility in placement for optimal airflow.

Technical Details

The Marathon C770V1 is a 1 HP, 1-phase motor operating at 1075 RPM with a 6-pole configuration. It features a Permanent Split Capacitor, Single Or Dual Voltage electrical type and a M56Y frame. The motor is thermally protected and rated for continuous duty. It includes a resilient base mounting and ball bearings on both drive and opposite drive ends. The keyed shaft has an extension of 6.00 inches. It is designed to operate in ambient temperatures up to 60°C and has an insulation class of B. The voltage rating is 460/200-230 V, with a current draw of 2.4/4.8 A. The motor is CSA recognized.
