US MOTORS 1973 OAO Blower Motor 1/2HP 1075RPM 230V 1Ph 48Y 1/2" Shaft
US MOTORS 1973 OAO Blower Motor 1/2HP 1075RPM 230V 1Ph 48Y 1/2" Shaft

US MOTORS 1973 OAO Blower Motor 1/2HP 1075RPM 230V 1Ph 48Y 1/2" Shaft

Trade-account pricing & availability.

Open a commercial account, or contact us, for pricing, availability, and pickup at Laval, Ville Saint-Laurent and Longueuil.

Availability by branch

  • Laval In stock
  • Longueuil In stock
  • Saint-Laurent In stock
Open an account Contact us
The US Motors 1973 is a 1/2 HP, 1075 RPM direct drive blower motor operating on 208-230V. It features 3 speeds, a 10.0 MFD capacitor, and draws 2.9 amps on a 1-phase circuit. The motor has a 5.6" diameter and is designed for continuous duty with air over cooling. It offers reversible rotation and automatic thermal overload protection. The frame is 48Y and it utilizes ball bearings.

Specifications

Voltage 230 V
Horsepower 1/2 HP
RPM 1075 RPM
Phase 1 Ph
Frame 48Y
Frequency 60 Hz
Shaft Diameter 1/2
