14EH Series Effluent Pump

Little Giant's 14EH Series Effluent Pump is engineered for demanding commercial effluent removal. This high-head series pump delivers consistent top performance for challenging high-flow applications. Built with a heavy-duty epoxy-coated cast iron housing and designed for continuous duty, it offers reliability and superior performance for dewatering, water transfer, and wastewater removal in residential, commercial, industrial, and agricultural settings. It handles liquids and solid waste materials up to 3/4 inch in diameter and features a high-speed 1/2 HP motor for high head operation.

Technical Details

The Little Giant 14EH Series Effluent Pump is a 1/2 HP, 115V submersible pump designed for high-head applications. It features a 1/2 HP Permanent Split Capacitor (PSC) motor with overload protection and operates at 3450 RPM. The pump has a 2" FNPT discharge and can handle 3/4" solids. Its performance includes a capacity of 60 gpm @ 20' and a shut-off head of 50'. The housing, volute, and impeller are made of epoxy-coated cast iron. It has a maximum liquid temperature rating of 140°F (60°C).

Technical Specifications
