3VX1120 SUPER HC V BELT

Engineered for demanding industrial applications, this Gates Super HC™ Molded Notch Belt offers a cost-effective and low-maintenance drive solution. Featuring a fiberglass tensile cord for high strength and excellent flex life, and a neoprene body for protection against grime, grease, oil, and moisture, this belt ensures long service life. Its durable nylon tooth facing provides a reliable wear surface, making it a maintenance-free and clean alternative for roller chain drive conversions. Experience increased capacity and improved registration with its specific sprocket groove profile design.

Technical Details

This Gates Super HC™ Molded Notch Belt, part number 3VX1120, is designed for industrial applications. It features a 3VX cross section, is notched, and has 1 rib and 1 strand. The belt has an effective length of 2844 mm (111.98 inches) and an outside circumference of 2845 mm (112 inches). The top width is 10 mm (0.39 inches), and the angle is 44 degrees. The thickness is 8 mm (0.31 inches). The construction utilizes a fiberglass tensile cord and a neoprene body with a nylon tooth facing.

Technical Specifications
