US MOTORS 8987VG TEFC Motor, 2HP, 1140RPM, 208-230/460V, 3PH, 56YZ Frame, 5/8" Shaft
US MOTORS 8987VG TEFC Motor, 2HP, 1140RPM, 208-230/460V, 3PH, 56YZ Frame, 5/8" Shaft

US MOTORS 8987VG TEFC Motor, 2HP, 1140RPM, 208-230/460V, 3PH, 56YZ Frame, 5/8" Shaft

Trade-account pricing & availability.

Open a commercial account, or contact us, for pricing, availability, and pickup at Laval, Ville Saint-Laurent and Longueuil.

Availability by branch

  • Laval In stock
  • Longueuil In stock
  • Saint-Laurent Not available
Open an account Contact us

Engineered for demanding commercial refrigeration applications, this Nidec-US Motors VariTough Inverter Duty Motor is designed to meet the rigorous requirements of 3 phase power and variable frequency drives (VFDs). It features an Inverter Duty rating, compliance with NEMA MG1-Part 31 standards, and an Open Drip-Proof, Shaft-up Design. Built for continuous duty air over operation with double sealed ball bearings, it offers reversible rotation and thermostat temperature protection. The motor includes a shaft ground ring for enhanced performance and reliability.

Technical Details

This Nidec-US Motors 8987VG is a 2 HP, 3-phase motor operating at 1140 RPM. It is designed for use with voltages of 208-230/460V and has an amperage rating of 7.8-7.8/3.9A. The motor features a NEMA frame size of 56YZ and a belly band mount. It is built with Class F insulation and can operate in ambient temperatures up to 70°C. The motor offers reversible rotation and includes thermostat temperature protection.

Technical Specifications

Voltage 208-230/460
Horsepower 2
RPM 1140
Phase 3
Frame Size 56YZ
Enclosure TEFC
Full Load Amps 7.8-7.8/3.9
Mounting Belly Band
Insulation Class F
Rotation Direction Reversible
Certifications Price
